640×512 Uncooled LWIR Network Imaging Module
Long-wave IR (LWIR): 8–14 μm
Spectra L06NT is a high-accuracy infrared module for general IP networks.
Spectra L06NT is a high-accuracy infrared module for general IP networks. Combining infrared array temperature measurement with IP networking, it supports a wide range of standard network protocols and ships with a rich, easy-to-use SDK. Compact and small in size, it delivers high measurement accuracy and a wide temperature range for integration into security monitoring, industrial inspection and other thermometry terminals that require online network support.
| Sensitive Material | Vanadium oxide (VOx) |
| Resolution | 640×512 |
| Pixel Pitch | 12μm |
| Spectral Band | 8μm ~14μm |
| Typical NETD | ≤20mK |
| Effective Pixels | 640×512 |
| Stream | 25Hz/30Hz |
| Video Encoding | H.264/H.265/MJPEG |
| Bit Rate | 100 K–8 Mbps configurable |
| Image Coding | JPEG |
| Boot-up Time | ≤10s |
| Digital Video Format | YUV420+Matrix-TEMP |
| Image Algorithms | NUC/DRC/DNS/DDE/SFFC |
| Image Display | 10 (white-hot / lava / iron-red / hot-iron / medical / arctic / rainbow-1 / rainbow-2 / red-trace / black-hot) |
| Network Protocols | TFTP, RTP, RTCP, RTSP, ONVIF, DHCP, GB/T 28181, UPnP, NTP |
| Storage | 32G EMMC |
| SDK / API | Windows / Linux |
| Standard Connector | 12PIN(A1257WV-S-12P)+RJ45 |
| Communication Interface | RS-232 / RS-422 / RS-485 (PELCO-D), 4800 bps |
| Network | 100M / 1000M Ethernet |
| Ambient Temp. for Measurement | -10℃~+50℃ |
| Measurement Range | −20℃–+150℃, 100℃–+550℃; extended ranges on request |
| Measurement Accuracy | ±2℃ or ±2% (whichever is greater) |
| Region Temperature | Region measurement with max / min / average output |
| Supply Range | DC 9–15 V; PoE |
| Typical Power | 3W@23±3℃ |
| Bare Dimensions (mm) | 45 mm×45 mm |
| 4.8 mm fixed | FOV 77.3°×65.2° · IFOV 2.5 mrad DRI (est.) 340/110/57 m |
| 7 mm fixed | FOV 57.5°×47.4° · IFOV 1.71 mrad DRI (est.) 500/170/83 m |
| 9.1 mm fixed | FOV 45.8°×37.3° · IFOV 1.32 mrad DRI (est.) 640/210/110 m |
| 13 mm fixed | FOV 32.9°×26.6° · IFOV 0.92 mrad DRI (est.) 920/310/150 m |
| 25 mm fixed | FOV 17.5°×14.0° · IFOV 0.48 mrad DRI (est.) 1800/590/300 m |
| Shock | Half-sine 40 g / 11 ms, 3 axes |
| Vibration | 5.35 g random vibration, 3 axes 6 directions |
| Ingress Protection | Window IP67 |
| Operating Temp. | -40℃～+70℃ |
| Storage Temp. | -45℃～+85℃ |
| Humidity | 5%–95%, non-condensing |
| RoHS / REACH | ROHS2.0/REACH |
Specifications subject to change without notice. D/R/I: estimated detection / recognition / identification range (m), Johnson criteria at 50% probability, standard human target 1.7 m × 0.5 m; actual range varies with scene and target.
