640 Polarimetric Long-wave Infrared Imaging Module
Long-wave IR (LWIR): 8–14 μm
640×512 polarimetric LWIR module at 7μm pixel pitch. Detects camouflaged targets and discriminates materials by polarization signature. CameraLink, 45×45mm.
640×512 polarimetric LWIR module at 7μm pixel pitch. Detects camouflaged targets and discriminates materials by polarization signature. CameraLink, 45×45mm.
| Spectral Band | Polarimetric Long-wave IR (LWIR): 8–14 μm |
| Resolution | 640×512 |
| Pixel Size | 7 μm |
| Compatible Lenses | Fixed-focus athermalized, Continuous zoom, Motorized focus, Dual FOV |
| Video Interface | CameraLink |
| Communication | RS232 |
| Dimensions | 45×45 mm |
| Power Supply | DC 12V |
A 10 μm, 1024×768 HOT cooled MWIR imaging module with a 144 mm athermalized lens, Camera Link output, ≤40 mK NETD, and compact 200×77×62 mm packaging.
A 640×512, 12 μm uncooled LWIR module shown with the 25 mm F1.0 fixed-focus athermalized lens — 50 Hz imaging, SDI/MIPI video output, RS422 control, and a 9.1–75 mm fixed-lens series.
A 1280×1024, 12 μm uncooled LWIR module shown with the 45 mm F1.0 fixed-focus athermalized lens — 25 Hz imaging, MIPI video output, RS422 control, ≤3 W steady-state power and ≤80 g module weight.
See the module and related imaging technology in real field footage.
Outdoor footage from a 640×512 thermal camera fitted with a 35 mm lens, focused on image clarity, field of view, and target presentation.
Watch Video
Multiple 640-channel thermal views are stitched into a 270-degree panorama for wide-area observation and continuous scene awareness.
Watch Video
Long-range Surveillance
Explore border & perimeter security applications
Industrial Inspection
Explore industrial inspection & monitoring applications
Law Enforcement
Explore security & surveillance applications
Environmental Protection
Explore agriculture & environment applications
Each card above links to a dedicated application page covering integration considerations, recommended module pairings and typical configurations. Don't see your scenario? Contact us for a tailored proposal.
